| Note: 32-bit systems support WIN7/WIN8/WIN10, but 64-bit systems do not support it.
Product performance:
1. Adopting the high-speed version USB2.0 standard interface, plug and play, with a transfer speed of up to 480MB/S, backward compatible with USB1.1 hosts, standard XDS510-USB2.0;
2. Standard Jtag emulation interface, does not occupy user resources, specially designed interface security protection, fully supports JTAG interface hot plugging;
3. Supports Windows 98/NT/2000/XP and Vista, WIN7 operating systems;
4. Supports integrated development environments for TICCS2. X, CCS3.1, CCS3.2, CCS3.3, and CCS4.12, and supports C language and assembly language;
5. Implement reliable Flash programming for F28x/F240x/F24x/F20x;
6. Fast simulation speed, supporting RTDX data exchange;
7.14-wire standard high-speed JTAG interface, does not occupy target system resources;
8. Automatically adapt to the DSP voltage of the target board;
9. Unique design, completely overcomes the system crash caused by the target board losing power, and solves the problem of CCS not being able to restart after the target board loses power;
10. Can simulate direct debugging of TI company’s TMS320C2000, TMS320C3000, TMS320C5000, TMS320C6000 and C
3X、C4X、C5X、C8X、OMAP、DM642、DM643、F28335、F2803X、F2802X、TMS320C6
72X and other full series DSP chips;
11. Support multi DSP debugging, a development system can debug multiple DSP chips on the board simultaneously;
12. For TI’s future chips, simply upgrade the software to easily apply them;
13. Easy to install, ready to use, stable operation, and low price;
14. Large scale production, using the best materials and processes for fully automatic surface mounting;
15. It has a target board detection function. If the target board is not connected or powered on, the simulator indicator light will turn green and a warning prompt will be displayed;
16. The stability and anti-interference ability have been greatly improved, and a new target board isolation circuit has been adopted. The isolation between the simulator and the target board is better, which improves the product’s performance
Anti interference capability, providing overcurrent and overload protection, has a certain protective effect on the rectifier and target board against overcurrent and overvoltage caused by incorrect operation. |
