KTAG 7.020 V2.25 Red PCB

8500.00 {Inc. GST}

GST Input Tax Credit is available

Dispatch Time 15 TO 20 Days

Available on backorder

SKU: OMP-PR021 Category:


KTAG 7.020 V2.25 with Red PCB refers to a specific version of the KTAG tool used for ECU (Engine Control Unit) programming and tuning in automotive applications.

“KTAG” stands for “K-TAG,” which is a widely used tool by automotive technicians and enthusiasts for reading, writing, and modifying the software (firmware) within ECUs. It allows users to perform tasks such as remapping the engine control parameters for performance enhancement, fuel efficiency, or troubleshooting purposes.

The version number “7.020” typically denotes the hardware version of the KTAG tool. The “V2.25” indicates the software version or protocol supported by the tool. Different versions may support different vehicle models, ECU types, and communication protocols.

The “Red PCB” refers to the color of the printed circuit board inside the KTAG tool. PCB color variations can sometimes indicate differences in hardware revisions, but in many cases, they are just aesthetic differences and may not have a significant impact on the functionality of the tool.

Overall, KTAG 7.020 V2.25 with Red PCB is a specific variant of the KTAG tool known for its compatibility with a wide range of ECUs and vehicle models, as well as its capability to support various programming and tuning tasks.

1. Please Only Use Our Software
2. Operating System: Better to Use Win XP
3. Tip (Very important): During operation, disable the internet connection; otherwise the software may get damaged.
1. What’s main different between Our K-TAG KTAG 7.020 and others?
-Mainly Different :  Our K-TAG 7.020 add a GPT cable to support GPT Functions ( GPT is new password algo cryptography that is implemented in new Tricore microcontrollers. our KTAG v7.020 can easily read and decrypt the secret password and it automatically unlocks/unprotects the Tricore sectors so it can read and write both Flash and Eeprom )
-No reset button ,no USB Dongle. NO Tokens Limited!!!
2. What is the advantage of KTAG V7.020 over than other EUC Chip Tuning Tools in the market?
-Supports online full protocols ,fully activated,without tokens limited.
-There are lot ECU that need to disassemble from the car and open and this is the case for all the ECU that need to be programmed with Jtag, BDM and Boot protocols, so KTAG is needed,as the new generation ktag master,ktag 7.020 is the best choice.
-K-TAG 7.020 can work For To-yot-a Hilux kun26 and new added 100+ ECU types & supports new car models e.g. T-oy-ota 76FXXX, P-S-A 17.4.4, Fo-rd E83, -VW 17.5.5 (1766), Me-rced-es-Be-nz 276 ECU, Toy-ot-a 76F, etc.
-KTAG V7.020 add a cable with GPT Functions.
-Online operation supported.
-Best PCB With Murata filters.
-Multi-Languages Supported .
-With a great performance and tested by many tuners and was regarded as one of the best ECU Programmer for trucks ,heavy duty,boat.
-No tokens limited, no years limited.
-No USB Dongle,No reset button.
3. KTAG v7.020 Red PCB ECU Tuning Tool Install/User Note
-The KTAG you received will with latest software 2.23 and hardware 7.020 ,so Never update it online.We will send you free update link in future.
-We don’t sell SD card and chips alone,sorry.
-We offer free Transdata dimsport software for Ktag 6070,but no install help in this free gift.
-Our KTAG 7.020 can be used online,no reset button need.No tokens limited
KTAG 7.020 Red PCB OBD2 Manager Tuning Kit PCB Display
K-TAG red PCB EU Version PCB Component!
1.  use of imported Japanese Murata NFE61PT472C1H9L filters
2. 2.8x WFs = Infineon, BCR112 NPN Digital Transistor
3. 3.7x 27E = ON Semiconductor NUP2105LT1G
4. 4.8x 6DW = NXP BC817215 NPN Bipolar Transistor
5. 5.3x A6c = MMUN2113LT1G / MMUN2113LT3G check your ktag PCB may already have 3 x A6c
6. 6.2x K5B = BC807-25-7-F PNP Bipolar Transistor
Package includes:
1 x KTAG 7.020 Main Unit
1 x 144300T 104
1 x 144300T 103
1 x 144300T 101
1 x 144300T 106
1 x 144300T 102
1 x 144300T 105
1 x 144300T 100
3 x Chips Inside
1 x Multi-Color Cable
1 x USB Cable
1 x Power Adapter

Additional information

Weight 500 g
