Description
Features
* Supports Windows XP (x86), and Windows Vista / 7 / 8 (x86/x64).
* USB 2.0 High-Speed Connection to Host PC.
* Supports MMCA V.4.51, 3.3 or 1.8V eMMC.
* eMMC Interface up to 8-bit.
* Supports eMMC BP, GP and ENH_USER Partition, Program and Verify.
* Supports C-Ming Technology eMMC duplicator’s Partition/Mirror/User/AutoScan Modes.
* Proprietary unitary file backup for all partition data, EXT_CSD settings, and checksum.
* Single partition access mode for BP, GP or user data supporting raw binary data.
* Easy to use, automatic parameter checking “eMMC Partition Settings” feature.
* Special BP1 + BP2 + User_Data mode.
* Special Bottom Align Mode.
Specification
Introduction
UPM-010e – USB Programmer is the handy tool for engineers working with eMMC.
UPM-010e comes with easy-to-use application allows user to identify, partition, read, program and/or verify eMMC. In addition to proprietary Partition/Mirror/User/AutoScan mode that supports C-Ming eMMC duplicator and raw binary mode, UPM-010e also supports special B1/2+U and Bottom Align mode to support certain specific application processor requirement.
Package Contents
UPM-010e Programmer *1 / USB Cable *1 / USB Flash Drive *1 (Driver/Software/Manual included)
