Description
PRODUCT DETAILS
The SIM7600CE is Multi-Band LTE-TDD/LTE-FDD/HSPA+/TD-SCDMA/EVDO and Dual-Band GSM/GPRS/EDGE module solution in a SMT type which supports LTE CAT4 up to 150Mbps for downlink data transfer. It has strong extension capability with rich interfaces including UART, USB2.0, SPI, I2C, GPIO etc.
SPECIFICATIONS
Quad-Band TDD-LTE B38/B39/B40/B41
Tri-Band FDD-LTE B1/B3/B8
Dual-Band TD-SCDMA B34/B39
Dual-Band WCDMA/HSDPA/HSPA+ B1/B8
GSM/GPRS/EDGE 900/1800 MHz
Control Via AT Commands
Supply voltage range: 3.4V~ 4.2V
Operation temperature: -40 to +85
Dimension: 30*30*2.9 mm
Weight: 5.5g
