TL631-Pro Diagnostic Card – Desktop PCI-E, Mainboard PCI-E, Notebook Debugging & Apple PC LPC Support

Features & Functions:

1. LPC1 High-Speed Channel – Connects to the motherboard 2.0 small-pin LPC interface (2.0 module). The LPC3 expansion interface can connect to a notebook MINI PCI-E conversion card, A-DEBUG conversion card, ASUS DEBUG-CON, or EC-DEBUG.

2. PCI High-Speed Channel – Supports all standard PCI slots.

3. LPC2 High-Speed Channel – Connects to the motherboard 2.54 large-pin LPC interface. Compatible with ASUS COM-DEBUG, ASRock UART1, MSI JDP, and Supermicro SPI.

4. PCI-E X1 High-Speed Channel – Supports Gigabyte motherboards without PCI slots (not supported by other brands).

5. 3VSB Power Indicator – Displays whether the power supply is functioning normally.

6. RST Reset Indicator – Checks motherboard reset status (active only when PCI or PCI-E is inserted).

7. CPU Indicator – Monitors the CPU module status.

8. DRAM Indicator – Detects whether the memory module is working properly.

9. VGA Indicator – Verifies the graphics card module status.

10. PCH South Bridge Indicator – Monitors the south bridge chip status.

11. DP Decimal Point (CLK Signal) – Displays clock signal status.

12. DP Decimal Point (FRAME Signal) – Displays frame signal status.

13. Accessory – Comes with a Banghoro gold cord or keychain.
