HX711 Load Cell Amplifier

120.00 {Inc. GST}

GST Input Tax Credit is available

5 in stock

SKU: OMP-M056 Category:


This Load Cell Amplifier is a small breakout board for the HX711 IC that allows you to easily read load cells to measure weight. By connecting the amplifier to your micro controller you will be able to read the changes in the resistance of the load cell and with some calibration you’ll be able to get very accurate weight measurements. This can be handy for creating your own industrial scale, process control, or simple presence detection. The HX711 uses a two wire interface (Clock and Data) for communication. Any microcontroller’s GPIO pins should work and numerous libraries have been written making it easy to read data from the HX711. Check the hookup guide below for more information. Connection for Wheatstone bridge to connect to the HX711, These are commonly colored Red, Black, White, Green. Each color corresponds to the conventional color coding of load cells: Red (Excitation+ or VCC), Black (Excitation- or GND), White (Amplifier+, Signal+, or Output+), and Green (A-, S-, or O-)


Operation Voltage: 2.7V-5V

Operation Current: < 1.5mA

Selectable 10SPS or 80SPS output data rate

Dispatch From:- Mumbai

Additional information

Weight 50 g
Item Code


Minimum Order Quantity

1 Piece


There are no reviews yet.

Be the first to review “HX711 Load Cell Amplifier”
