DB9 Female to 3.5mm audio Serial Cable-6 Feet

Description

DB9 Female to 3.5mm audio Serial Cable-6 Feet

• 6ft DB9 Female to 3.5mm Serial Cable
• Serial Transfer Cable For Devices
• Stereo 3.5 mm Jack to DB9-F Serial Port.
• Primarily used to transfer Serial Data back and forth from Small devices.
  Wiring Schematic
  DB9 TRS Connector 3.5mm
  Pin 1-6-7-8
  Pin 2 Tip – Left
  Pin 3 Ring – Right
  Pin 4
  Pin 5 Shield – Ground
  Pin 9
