Description
ESP32-WROOM-32 is a powerful, generic Wi-Fi+BT+BLE MCU module that targets a wide variety of applications, ranging from low-power sensor networks to the most demanding tasks, such as voice encoding, music streaming and MP3 decoding.
| Test | Reliablity | HTOL/HTSL/uHAST/TCT/ESD |
| Wi-Fi | Protocols | 802.11 b/g/n (802.11n up to 150 Mbps) A-MPDU and A-MSDU aggregation and 0.4 s guard interval support |
| Frequency range | 2.4 GHz ~ 2.5 GHz | |
| Bluetooth | Protocols | Bluetooth v4.2 BR/EDR and BLE specification |
| Radio | NZIF receiver with –97 dBm sensitivity
Class-1, class-2 and class-3 transmitter AFH |
|
| Audio | CVSD and SBC | |
| Hardware | Module interfaces | SD card, UART, SPI, SDIO, I2C, LED PWM, Motor PWM, I2S,IR, pulse counter, GPIO, capacitive touch sensor, ADC, DAC |
| On-chip sensor | Hall sensor | |
| Integrated crystal | 40 MHz crystal | |
| Integrated SPI flash | 4 MB | |
| Operating voltage/Power supply | 2.7 V ~ 3.6 V | |
| Operating current | Average: 80 mA | |
| Minimum current delivered by power supply |
500 mA | |
| Recommended operating temperature range | –40 °C ~ +85 °C | |
| Package size | (18.00±0.10) mm x (25.50±0.10) mm x (3.10±0.10) mm |
