MY1016Z2 24V 250W Electric Scooter Brushed DC Gear Motor for Electric Bicycle

3200.00 {Inc. GST}

GST Input Tax Credit is available

SKU: OMP-E009 Category: Tag:

Description

MY1016Z2 24V 250W Electric Scooter Brushed DC Gear Motor for Electric Bicycle
SPECIFICATIONS:
Model name:- MY1016Z
24 Volt DC Operation
No Load RPM: 3850
No Load Current: <2.2 Amps
Rated Wattage: 250W (0.33 Horsepower)
Permanent Magnet DC Motor
Rated Current: 13.4 Amps
Efficiency: 78%
Reduction Ratio: 9.78:1
Rated Load RPM: 400
Torque (NM): 22
Direct Drive (No Free Spooling)
Suitable for Forward and Reverse Operations
Base Mount Model
9 Tooth Sprocket for 1/2″ x 1/8″ Pitch Chain
This motor is capable of rotation in either clockwise or counter clockwise by reversing the motor’s power wires.
For Chain Size: Pitch 0.5in; Roller Diameter 0.3in; Roller Width 0.16in

Additional information

Weight 2000 g
Item Code

OMP-E009

Minimum Order Quantity

1 Piece
