Ebike Scooter Brushless Dc Motor Controller 48v 350w

Description

EBIKE SCOOTER BRUSHLESS DC MOTOR CONTROLLER 48V 350W
Specifications:
Voltage: 48V
Wattage: 48V 350W
Throttle: 1-4V
Short voltage protect: 31.5 0.5V/42 0.5V
Color: silver
Dimension: 105 x 65 x 32mm/4.13 x 2.56 x 1.26″
Casing material: Aluminum
Note: It only fit for Motor with sensors.

Operation:
1. Blue/Black – cruise/ground
2. White wire – self-learning (plug two white wire together)
3. White/Black – Brake (low)/brake (low)
4. Purple – Brake (high)
5. Red/Black/Green – throttle positive/throttle negative/throttle signal
6. Red/Black/thin Yellow/thin blue/thin green – +5V//Earthing/Motor Hall lines
7. Thin Blue – instrument
8. Red/Blue/Black – +5V/Signal/Earthing (Pedal Assistant)
9. Thick Blue/thick Yellow/Thick Green – Motor phase lines
10. Thick Red/thick Black/thin red – power positive/power negative/power lock

Package includes:
1 x Brushless motor controller
